Motherboard Gaming Edition (especial para juegos)
placa madre basada en chip x79 especial para pc gamer, formato MATX, hasta 128gb en cuatro canales, pcie x16, x4, x1 .Sonido 7.1 , slot m2 y sata3 . lineas de poder protegidas y con disipación.
Jingsha es el fabricante lider en plataformas x79 y esta es una de las mejores placas madres para esta plataforma con una solida fabricacion
Model Name X79 MATX Extreme gaming motherboard with Intel 7 series chipset & LGA 2011 socket quad channels DDR3 up to 64GB support 1866mhz
Highlight X79 Intel motherboard ddr3 mainboard lga 2011 mother board m.2 system board pc board
gaming motherboard desktop computer motherboard workstation pc motherboard main board
matx motherboard 1866 MHz
ddr3 64gb
m.2 nvme sata3.0 pci-e 3.0 16x 7.1 doby suround stereo
CPU Support LGA2011 Socket of Intel® Core™ series processors
Intel Xeon series processors
Chipset Intel 7 series Chipset
Memory Support Quad channelsDDR3 1066/1333/1600/1866 MHz
4 x 240 Pin DDR3 SDRAM Memory Slots
Support maximum up to 64GB Memory
Expansion Slots 1 x PCI-E 3.0 x 16 Slot
1 x PCI-E x 1 Slot
1 x PCI-E x 4 Slot
1 x M.2 Port
Storage 1 x SATA3 Connector (6Gb/s)
3 x SATA2 Connector (3Gb/s)
LAN Realtek RTL8118E - 100/1000 LAN Controller
Audio ALC892
USB Ports 8 x USB 2.0 (4 at Back Panel; 4 at mid-board USB Header)
4 x USB 3.0 (2 at Back Panel; 2 at mid-board USB Header)
Rear I/O Ports 2 x PS/2 Keyboard/Mouse
4 x USB 2.0
2 x USB 3.0
1 x RJ-45 Port
6 x Audio ports, Support 7.1 Sound Audio Jack
Internal I/O Ports 1 x CPU Fan Header
1 x System Fan Header
1 x Front Audio Header
1 x SPDIF header
1 x USB 3.0 20-Pin Header
2 x USB 2.0 Header (each header support 2 USB Ports)
1 x CLR_CMOS Header
1 x Front Panel Header
1 x Debug Header
1 x BZ1_Power
1 x SATA3 6Gb/s Connectors, Support AHCI
3 x SATA2 3Gb/s Connectors
1 x 24-pin ATX Power Supply Header
1 x 8-pin ATX 12V Power Supply Header
Accessories 1 x I/O Shield
1 x SATA cable
BIOS AMI BIOS, Support Advanced Power Management ACPI
Operating System Supports Windows 7/10
Form Factor MATX Form Factor, 25.5 x 19.5 cm
